Note
• Use Manual
Band Adj for transparent media or other paper for which adjustment with Auto Band Adj. is
not possible.
• Either B:Standard/Draft or A:High in the Adjust Length menu is applied, depending on printer driver set-
tings at the time of printing.
• If you have selected Easy Settings in the printer driver, follow these steps to confirm the Print Priority
setting.
• Windows: Click View Settings on the Main tab to display the View Settings dialog box.
• Mac OS X: Click View set. on the Main pane to display the View settings dialog box.
Follow these steps to change the Feed Priority setting.
1. Press the Menu button to display MAIN MENU.
2. Press ▲ or ▼ to select Paper Details, and then press the ▶ button.
3. Press ▲ or ▼ to select the type of paper, and then press the ▶ button.
4. Press ▲ or ▼ to select Feed Priority, and then press the ▶ button.
5. Press ▲ or ▼ to select Automatic, Band Joint or Print Length and then press the OK button.
Auto Band Adjustment (Auto Band Adj.)
If printed images are affected by banding in different colors, adjust the amount that paper is fed.
Auto Band Adj. offers two modes, Standard Adj. and Advanced Adj.. Use Advanced Adj. if Standard Adj. does not
eliminate banding, or when using paper other than genuine Canon paper or paper for purposes other than checking output.
Always check the Feed Priority setting before using Auto Band Adj.. (See "Selecting a Feed Amount Adjustment
Method (Feed Priority).") →P.676
Note
• When
using highly transparent media not compatible with Auto Band Adj., you must adjust the feed amount
manually. (See "Manual Band Adjustment (Manual Band Adj).")
→P.678
• If
additional fine-tuning is necessary after Auto Band Adj., use Fine Band Adj.. (See "Banding Adjust-
ment During Printing (Fine Band Adj.).")
→P.680
• To
adjust the measurement scale and ensure accuracy (so that lines in CAD drawings are printed at exactly
the right length, for example), specify the amount of paper stretching or shrinkage when adjusting the feed
amount. (See "Adjusting Line Length (Adjust Length).")
→P.681
• This may take some time, depending on the type of paper.
• Use paper of the same type and size for adjustment as you will use for printing.
Adjustments for Better Print Quality
> Adjusting the feed amount >
iPF815 Auto Band Adjustment (Auto Band Adj.)
8
677

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
