Canon imagePROGRAF iPF815 User Manual

No Spaces at Top or Bottom
You can save paper on not to feed roll paper for the empty spaces when the print data contains spaces at the top or bottom.
For more information about No Spaces at Top or Bottom, see "Not Print Spaces at the Top/Bottom."
→P.255
Note
• Available only if rolls are selected in Paper Source.
Print Button
Click the button to start printing.
Cancel Button
Click the button to stop printing.
Printer Information
You can confirm the information acquired from the printer.
Update Printer Information Button
Click the button to update the printer information with connecting to the printer.
Status Monitor Button
Click the button to start Status Monitor.
Enlarge/Reduce the screen display
You can enlarge or reduce the screen display when you select Zoom from the View menu.
Setting Details
Fit Screen Display all.
Fit to Width Display to the width of the paper.
Reduce Display at half of the standard size.
Standard Display at the standard size.
Enlarge Display with the double of the standard size.
Enlarge More Display with the triple of the standard size.
Note
• This item can be selected even if you have clicked the ▼ button in the toolbar Zoom.
Moving a Page
You can move a page to display when you select Go to Page from the View menu.
Windows Software
> Preview >
iPF815 Enlarge/Reduce the screen display
4
249

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
