4. Press ▲ or ▼ to select Fine Band Adj., and then press the ▶ button.
5. Press ▲ or ▼ to change the value, and then press the OK button.
Note
• The supported range is –5 to +5.
6. Press the Online button to resume printing.
Adjusting Line Length (Adjust Length)
Use Adjust Length to ensure that lines in CAD drawings are printed at exactly the right length.
In the Adjust Length menu, choose the mode of length adjustment ( A:High or B:Standard/Draft ) that suits your particu-
lar printing application.
•
A:High : This setting is applied when Highest or High is selected in Print Quality in the printer driver.
• B:Standard/Draft : This setting is applied when Standard or Draft is selected in Print Quality in the printer driver.
Check the Feed Priority setting before using Adjust Length. (See "Selecting a Feed Amount Adjustment Method
(Feed Priority).")
→P.676
Note
• Use paper of the same type and size for adjustment as you will use for printing.
• If you have selected Easy Settings on the printer, follow these steps to confirm the Print Quality setting.
• Windows: Click View Settings on the Main tab to display the View Settings dialog box.
• Mac OS X: Click View set. on the Main pane to display the View settings dialog box.
Paper to Prepare
Rolls An unused roll at least 10 inches wide
Sheets One sheet of unused paper of at least A4/Letter size
Follow these steps to change the Adjust Length setting.
1. Load paper.
• Attaching the Roll Holder to Rolls →P.623
• Loading Rolls in the Printer →P.628
• Loading Sheets in the Printer →P.651
Adjustments for Better Print Quality
>
Adjusting the feed amount
>
iPF815 Adjusting Line Length (Adjust Length)
8
681
To Next Page
