The following settings are available for the finished size.
Setting Details
Fit Roll Paper Width Prints by automatically enlarging or reducing the entire document so that the width
of the document matches the roll paper width.
Specify Folded Size Prints by automatically enlarging or reducing the entire document to match the size
of the paper. Select the actual size of the paper you want to print on in Fit Paper
Size.
Rotate Page 90 degrees (Con-
serve Paper)
Prints by rotating pages by 90 degrees. Pages are automatically rotated if they will
fit within the roll paper width when rotated, and are not rotated if they will not fit
within the roll paper width.
Binding Settings Dialog Box
This is displayed when you select Binding Settings from the Edit menu. This allows you to configure the binding edge
settings.
Binding Edge
Configures the binding edge when folding paper.
The following settings are available for the binding edge.
Setting Details
Bottom Prints by placing the binding margin (gutter) at the bottom of the document.
Top Prints by placing the binding margin (gutter) at the top of the document.
Binding
Configures the binding margin (gutter).
Prints by creating a binding margin (gutter) of the specified size. Enter the margin size as a number.
Note
• The values that can be entered are 0 to 50 (mm).
Windows Software
> Free Layout >
iPF815 Binding Settings Dialog Box
4
283

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
