Canon imagePROGRAF iPF815 User Manual

Printer Specifications
Specifications .................................................................................................................................................. 765
Print Area ........................................................................................................................................................ 768
Specifications
Important
• The following values may vary depending on the operating environment.
Printer
Power supply 100–120 V AC (50/60 Hz), 220–240 V
AC (50/60 Hz)
Power consumption During operation 190 W max.
Sleep mode 100–120 V: 5 W max.
220–240 V: 6 W max.
Off 1 W max. (*1 →P.765 )
Operating noise During operation Approx. 52 dB (A) max. (6.8 bels or
less)
Standby Approx. 35 dB (A) max.
Operating environment Temperature 15–30°C (59–86°F)
Humidity 10–80%, non-condensing
Dimensions (W × D × H) Printer and Stand (including Roll
Holder and Stationary Output Stack-
er )
1,893 ×975×1,144 mm (74.5 × 38.4 ×
45.0 in)
Weight Printer and Stand (not including the
Printhead and Ink Tank )
Approx. 138 kg (304.2 lb)
Space for installation (W × D × H) Printer and Stand (not including the
Printhead and Ink Tank )
2,293×1675×1,500 mm (90.3 × 65.9 ×
59.1 in)
Applicable standards International Energy Star Program, Law
on Promoting Green Purchasing, GPN,
RoHS, Eco Declaration, WEEE, U.S.
presidential directives
*1: The printer uses a trace amount of power even when turned off. To stop all power consumption, turn off the
printer and unplug the power cord.
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi horizontally (*1 →P.765 ) × 1200 dpi vertically
Printhead PF-03
Number of nozzles MBK: 5,120; Others: 2,560 each color
*1: Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Printer Parts
> Printer Specifications >
iPF815 Specifications
9
765

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
