Canon imagePROGRAF iPF815 User Manual

Printing CAD Drawings
Printing CAD Drawings ..................................................................................................................................... 19
Printing Line Drawings and Text ....................................................................................................................... 19
Printing Line Drawings and Text (Windows) ................................................................................................. 20
Printing Line Drawings and Text (Mac OS X) ............................................................................................... 22
Specifying Colors and Printing CAD Drawings ................................................................................................. 26
Specifying Colors and Printing CAD Drawings (Windows) ........................................................................... 27
HP-GL/2 Printing ............................................................................................................................................... 28
Printing CAD Drawings
Using this printer, you can print fine lines and text clearly and sharply. It's easy to produce highly precise drawings from
CAD applications.
Note
• In
Windows, you can print highly precise drawings using the provided imagePROGRAF HDI Driver for Au-
toCAD/AutoCAD LT.
For details on the HDI driver, see the HDI Driver
→P.354 .
For instructions on CAD printing, refer to the following topics, as appropriate for your computer and operating system.
• Printing Line Drawings and Text (Windows) →P.20
• Printing Line Drawings and Text (Mac OS X) →P.22
Printing Line Drawings and Text
Printing is easy when you simply choose the type of original to print.
Easy Settings
Simply choose the printing application in the list for optimal printing results.
Print Target
Choose presets that match the type of document to be printed.
Print targets for line drawings and text
Print Target Description
CAD (Color Line Draw-
ing)
Settings optimized to print intricate lines in CAD draw-
ings clearly.
Working With Various Print Jobs
> Printing CAD Drawings >
iPF815 Printing CAD Drawings
2
19

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
