Canon imagePROGRAF iPF815 User Manual

Item Details Default Setting
Zone (*2) However, do not use the following single-byte characters: @, :, and =. Also avoid us-
ing * (which represents the default zone) in the middle of a string.
*
*1:The object name you have specified in Name is
displayed in Printer Setup Utility (or Print Center ) in Mac OS
X 10.2.8–10.4. If you use multiple printers in the same zone, assign a unique name to each printer. By default,
the network interface name is Canon NB-17FB (xxxxxx). (Here, xxxxxx is the last six digits of the printer's
MAC address.)
*2: If zones have been created on the network, enter the name of the printer's zone. If there are no zones, leave the
asterisk * entry (for the default zone) as it is. If you enter a network zone name that does not match created
zones, the printer will not be detected by Macintosh computers. Consult your network administrator for informa-
tion on zone names.
7. Click OK to display the Network page.
Configuring the Destination for AppleTalk Networks
To print over an AppleTalk network, activate the AppleTalk protocol and configure the destination as follows.
Activating AppleTalk on the printer
Important
• By factory default, the AppleTalk protocol is disabled on the printer.
1. Press the Menu button to display MAIN MENU.
2. Press ▲ or ▼ to select Interface
Setup, and then press the ▶ button.
3. Press ▲ or ▼ to select AppleTalk, and then press the ▶ button.
4. Press ▲ or ▼ to select On, and then press the OK button.
Network Setting
> Network Setting (Mac OS X) >
Configuring the Destination for AppleTalk Networks iPF815
10
794

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
