Canon imagePROGRAF iPF815 User Manual

Problems with the printing quality
Printing is faint ................................................................................................................................................. 866
Paper rubs against the printhead .................................................................................................................... 867
The edges of the paper are dirty ..................................................................................................................... 868
The surface of the paper is dirty ...................................................................................................................... 868
The back side of the paper is dirty .................................................................................................................. 869
Printed colors are inaccurate ........................................................................................................................... 869
Banding in different colors occurs ................................................................................................................... 870
Colors in printed images are uneven ............................................................................................................... 870
Image Edges are Blurred or White Banding Occurs ....................................................................................... 871
Setting the Blue Switch on the Platen ......................................................................................................... 872
The contrast becomes uneven during printing ................................................................................................ 875
The length of printed images is inaccurate ...................................................................................................... 875
Documents are printed crooked ...................................................................................................................... 875
Documents are printed in monochrome .......................................................................................................... 875
Line thickness is not uniform ........................................................................................................................... 876
Lines are misaligned ....................................................................................................................................... 876
Problems with the printing quality caused by the type of paper ...................................................................... 877
Printing is faint
Cause Corrective Action
You may be printing on the wrong
side of the paper.
Print on the printing surface.
The Printhead nozzles are clogged. Print a test pattern to check the nozzles and see if they are clogged.
(See "Checking for Nozzle Clogging.") →P.817
Because the printer was left without
ink tanks installed for some time,
ink has become clogged in the ink
supply system.
After the ink tanks have been installed for 24 hours, run Head Cleaning B.
(See "Cleaning the Printhead.") →P.819
Paper is jammed inside the Top
Cover.
Follow the steps below to remove the jammed piece of paper inside the Top
Cover.
1. Press the Online button to bring the printer offline.
2. Open the Top Cover and make sure the Carriage is not over the Platen.
3. Remove any scraps of paper inside the Top Cover.
(See "Clearing Jammed Roll Paper.") →P.852
(See "Clearing a Jammed Sheet.") →P.856
4. Close the Top Cover.
During borderless printing, the ink
was not dry enough before cutting.
Specify a longer drying period in the printer menu, in Roll DryingTime in Pa-
per Details.
(See "Main Menu Settings.") →P.722
Printing may be faint if Print Qual-
ity in Advanced Settings in the
printer driver is set to Standard or
Draft.
In Advanced Settings of the printer driver, choose Highest or High in Print
Quality.
Printing in Draft or Standard mode is faster and consumes less ink than in
Highest or High modes, but the printing quality is lower.
Troubleshooting
> Problems with the printing quality >
Printing is faint iPF815
12
866

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
