Canon imagePROGRAF iPF815 User Manual

Setting Details
Printer Default The settings of the printer operating panel are applied.
Fast Select this setting if cutting with the Standard setting is not clean.
Standard Select this setting when you are not experiencing problems.
Slow Select this setting if cutting with the Standard setting is not clean.
Output Method Dialog Box
Output Method dialog box appears when you click Output Method button on the Main sheet in the Custom Properties
dialog box. You can specify the output method for HDI Driver.
Setting Details
Print Normal printing. The print job data is stored temporarily in the box as the job prints
Save in mail box The print data is saved in the mail box on the HDD without printing.
Sets the number of the destination mail box for saving. The name of the data to be
saved is displayed.
Color Compatibility Dialog Box
Color Compatibility dialog box appears when you click the Color Compatibility button on the Main sheet in the Custom
Properties dialog box. You can set color for when Color (CAD) is selected in Color Mode.
You can print with color approximating the specified model by selecting Color Compatibility for printing.
Note
• Color (CAD) is displayed by selecting the Main sheet, and then Line Drawing/Text in Print Priority.
Windows Software
> HDI Driver >
Output Method Dialog Box iPF815
4
382

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
