Canon imagePROGRAF iPF815 User Manual

Free Layout
The Features of Free Layout ........................................................................................................................... 481
Operating Environment ................................................................................................................................... 481
Starting Free Layout ........................................................................................................................................ 482
Free Layout Main Window ............................................................................................................................... 483
Paper Settings Panel ....................................................................................................................................... 486
Easy Settings .............................................................................................................................................. 488
Advanced Settings ...................................................................................................................................... 489
Color Settings Panel ........................................................................................................................................ 491
Color Adjustment ......................................................................................................................................... 492
Matching ...................................................................................................................................................... 495
Driver Matching Mode ............................................................................................................................. 497
ICC Matching Mode ................................................................................................................................ 498
ColorSync ................................................................................................................................................ 499
Preferences Dialog Box ................................................................................................................................... 500
Page Setup Dialog Box ................................................................................................................................... 501
Zoom Dialog Box ............................................................................................................................................. 502
Format Dialog Box ........................................................................................................................................... 503
Laying out a Multiple-File Document on One Page ......................................................................................... 504
Laying out a Document Created with Multiple Application Programs on One Page ....................................... 504
Selecting an Object ......................................................................................................................................... 505
Changing the Object Size ................................................................................................................................ 505
Moving an Object ............................................................................................................................................ 506
Rotating an Object ........................................................................................................................................... 507
Laying out Objects Automatically .................................................................................................................... 508
Aligning Objects .............................................................................................................................................. 508
Changing the Object Overlapping Order ......................................................................................................... 510
Pasting a Copied or Cut Object ....................................................................................................................... 512
The Features of Free Layout
The main features of Free Layout are as follows.
• Allows you to lay out at will and print a document created with application software.
• You
can not only lay out multiple pages on one page but also lay out and print a multiple-file document on one page,
or lay out and print a document created with multiple application programs on one page.
Note
• The
media type, image size, detailed media settings, and the printer settings can cause the actual print output
to differ from the Free Layout settings.
Operating Environment
You can use the Free Layout in the following environments.
• Compatible Operating System
Mac OS X (10.3.9 to 10.6)
• Software that requires installation
imagePROGRAF Printer Driver
Mac OS X Software
> Free Layout >
iPF815 The Features of Free Layout
5
481

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
