Paper jam.
"Lift the release lever."
Cause Corrective Action
A paper jam occurred
in the printer during
printing.
1. Lift the Release Lever and remove the jammed paper.
(See "Clearing Jammed Roll Paper.") →P.852
(See "Clearing a Jammed Sheet.") →P.856
2. If
"Not finished printing. Finish printing remaining jobs?" is shown on the Display
Screen, press the OK button.
Printing will resume, starting from the page on which the error occurred.
"Manually rewind the roll all the way and press OK."
Cause Corrective Action
A paper jam occurred
when advancing the pa-
per.
1. Rewind paper on the Roll Holder manually, all the way, and then press the OK button.
2. If
"Not finished printing. Finish printing remaining jobs?" is shown on the Display
Screen, press the OK button.
Printing will resume, starting from the page on which the error occurred.
Paper loaded askew.
Cause Corrective Action
Paper is loaded askew. Follow these steps to reload the roll.
1. Lift the Release Lever.
2. Open the Top Cover.
3. Adjust
the right edge of the roll to make it parallel to the
right Paper Alignment Line.
4. Lower the Release Lever.
5. Close the Top Cover.
(See "Loading Rolls in the Printer.")
→P.628
If this error recurs after you reload the roll, remove the Roll
Holder from the printer, push the roll firmly in until it touches
the Roll Holder flange, and reload the Roll Holder in the print-
er.
(See "Attaching the Roll Holder to Rolls.") →P.623
Follow these step to reload a sheet.
1. Lift the Release Lever.
2. Open the Top Cover.
3. Adjust
the right edge of the sheet to make it parallel to the
right Paper Alignment Line and the trailing edge of the
sheet to make it parallel to the paper alignment line under
the Paper Retainer.
4. Lower the Release Lever.
Error Message
> Messages regarding paper >
Paper jam. iPF815
13
900

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
