Cause Corrective Action
The Cutter Unit stops in
the middle of cutting.
(See "Specifying the Cutting Method for Rolls.") →P.642
In other cases, the Cutter
Unit may be damaged.
Contact your Canon dealer for assistance.
End of paper feed.
Cause Corrective Action
You are pressing the ▲ button on the Control Panel and trying to rewind the roll to the edge. Release the ▲ button.
Paper can be retracted only up to 17 mm (0.7 in) when using the Media Take-up Unit. Release the ▲ button.
Rel lever is in wrong position.
Cause Corrective Action
The Release Lever is up. Lower the Release Lever.
If the error occurs again, turn off the printer and wait a while before restoring power.
Rewinding error.
Cause Corrective Action
There is some foreign object near the Media Take-up Unit sensor
and the roll cannot be detected.
Remove the foreign object near the sensor.
The Media Take-up Unit sensor is soiled and the roll cannot be de-
tected.
Wipe the sensor with a dry cloth to clean it.
The roll is out of range of detection by the Media Take-up Unit sen-
sor.
Reload the roll.
(See "Loading Rolls in the Printer.") →P.628
The Media Take-up Unit sensor is damaged. Contact your Canon dealer for assistance.
A paper jam has occurred and the roll cannot be rewound. Remove the paper from the Media Take-up Unit.
Press the Online button to clear the error.
*Printing will stop momentarily if an error involving the Media Take-up Unit occurs. If you prefer printing not to
stop, set Skip Take-Up Err to On.
Media take-up unit ready.
Cause Corrective Action
The Take-up Reel setting in the printer MAIN MENU
was changed from Enable to Disable, but a print job was
received before the roll was removed.
Press the Stop button and stop printing.
The mode switches from take-up mode to regular mode af-
ter you change the Take-up Reel setting in the MAIN
MENU from Enable to Disable and lift the Release Lever,
or after you execute Paper Cutting.
Error Message
> Messages regarding paper >
End of paper feed. iPF815
13
902

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
