Adj. Pale Color Recognizable
When you place a checkmark here, yellow or cyan lines or other portions of images that are difficult to see when printed in
white space can become easier to see.
Economy Printing
You can reduce the amount of ink consumed for printing by placing a checkmark here.
Increase image print speed (AutoCAD2011 only)
When you print with the resolution configured to 600dpi, you can print data including raster images even faster.
However, image quality may deteriorate if high-resolution raster images are included. Remove the check in this case.
Output Method Button
Click the button to open the Output Method dialog box and you can specify the output method for HDI Driver.
For more information about the output method, see "Output Method Dialog Box." →P.382
Color Compatibility button
Click the button to open the Color Compatibility dialog box, and you can set color for when Color (CAD) is selected in
Color Mode.
For more information on setting color compatibility, see "Color Compatibility Dialog Box."
→P.382
Paper Detailed Settings
To open the Paper Detailed Settings dialog box, click Settings button of the Media Type in the Custom Properties dia-
log box. You can perform the settings for ink drying time of each media and other features.
Windows Software
> HDI Driver >
Paper Detailed Settings iPF815
4
380

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
