Canon imagePROGRAF iPF815 User Manual

Cause Corrective Action
You are using a paper that
does not dry easily.
In this case, in the Control Panel menu, complete the settings for Dry time and Area
in Scan Wait Time.
However, note that printing will now take longer.
(See "Main Menu Settings.") →P.722
The back side of the paper is dirty
Cause Corrective Action
The Platen has become dirty after borderless print-
ing or printing on small paper.
Open the Top Cover and clean the Platen.
(See "Cleaning Inside the Top Cover.") →P.837
Set CarriageScanWdth to Fixed.
The Platen has become soiled due to printing on the
Platen because width detection is deactivated.
Activate width detection, and open the Top Cover and clean the
Platen.
(See "Cleaning Inside the Top Cover.") →P.837
Open the Top Cover and clean the Platen. After this, manually
advance the roll onto the Platen before printing.
(See "Cleaning Inside the Top Cover.") →P.837
(See "Feeding Roll Paper Manually.") →P.638
The Paper Retainer is soiled. Clean the Paper Retainer.
(See "Cleaning Inside the Top Cover.") →P.837
Printed colors are inaccurate
Cause Corrective Action
Color adjustment has not been activated in the Ad-
vanced Settings of the printer driver.
In the Advanced Settings of the printer driver, access Color Set-
tings in Color Mode to adjust colors.
Colors have not been adjusted on the computer or
monitor.
Refer to the computer and monitor documentation to adjust the
colors.
Adjust the settings of the color management software, referring to
the software documentation as needed.
The Printhead nozzles are clogged. Print a test pattern to check the nozzles and see if they are clog-
ged.
(See "Checking for Nozzle Clogging.") →P.817
In the Windows printer driver, Application Color
Matching Priority is not selected.
Click Special Settings on the Layout sheet of the printer driver
and select Application Color Matching Priority in the dialog
box.
Printhead characteristics gradually change through
repeated use, and colors may change.
Adjust the Printhead alignment.
(See "Automatic Straightening of Lines and Colors (Auto
Head Adj.).") →P.668
(See "Manual Straightening of Lines and Colors (Manual
Head Adj).") →P.670
Troubleshooting
> Problems with the printing quality >
iPF815 The back side of the paper is dirty
12
869

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
