109
2.13.8 Sensor & Motor (Menu code 1734)
( MENU → 7. Print → 3. Printer Hardware → 4. Sensor&Motor )
This Menu allows you to program the Print Method type by activating or deactivating
the Peel Off sensor, Rewind motor and selecting gap or no gap type label stock.
Note: Be sure to select the appropriate values for the type of Print Method you are
using.
• If there is no gap on a label, set Label
Paper to 0, if there a gap, set it to 1.
• When “Ticket Mode” is in “Print Mode”,
[Rewind Motor] and [Label Paper] do not
work.
2.13.9 Print Intensity (Menu code 1735)
( MENU → 7. Print → 3. Printer Hardware → 5. Print Intensity )
This Menu allows you to program the Print Intensity level. (Print darkness) The higher
the number the darker the print will be. Pressing the TEST key will issue a sample label
to verify the Print Intensity setting.
• You must press the SAVE key to save
the setting and exit.
2.13.10 Adjust Feed Length (Menu code 1736)
( MENU → 7. Print → 3. Printer Hardware → 6. Adjust Feed Length )
This Menu allows you to make minor adjustments to the Feed Length which will result
in the print information moving up(+) or down (-) on the Label or Ticket.
Note: Feed Length Adjustment range is -200 to +200. Plus or Minus is controlled by the ZERO
key.
• Value: 1 = 0.125mm
Ex.) “+8” will print 1mm higher
“-8” will print 1mm lower
