Cisco SPS208G User Manual

Network Security
ACL Binding
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 115
7
• ACL Name — Indicates the ACL which is bound to the associated interface.
The possible values are:
- IP Based ACL — Select an existing IP Based ACL to bind with the
interface.
- MAC Based ACL — Select an existing MAC Based ACL to bind with the
interface.
STEP 2 Define the relevant fields.
STEP 3 Click Add To List. The ACL binding is defined, and it is listed in the table at the
bottom of the
ACL Binding Screen .
To delete an ACL Binding configuration:
STEP 1 Click Network Security > ACL Binding. The ACL Binding Screen opens.
STEP 2 In the table, select the ACL Binding entry to delete.
STEP 3 Click Delete. The ACL Binding configuration is removed from the ACL Binding
Table and deleted from the device.

Cisco SPS208G Specifications

General

Brand	Cisco
Model	SPS208G
Category	Switch
Language	English
