Statistics
Port Utilization
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 85
5
Port Utilization
The
Port Utilization Screen
displays the amount of resources each interface is
currently consuming. Ports in green are functioning normally, while ports in red are
currently transmitting an excessive amount of network traffic.
To view port utilization:
STEP 1 Click Statistics > Port Utilization. The
Port Utilization Screen
opens.
Figure 38 Port Utilization Screen
For 24-port devices, the
Port Utilization Screen
displays the ports on multiple
screens. To browse to a specific port entry, click the Previous, 1, 2, 3, 4, and Next
links above the table. To view all device ports in the same window, click View All
Ports.
The
Port Utilization Screen
contains the following fields:
• Unit No. — Indicates the stacking member being managed.
• View All Ports — Displays all ports per unit.
