Internal USB card kit
The internal USB card kit contains one internal USB card. For installation of internal USB card, see installing the internal USB
card section.
NOTE: Ensure to install the internal USB card in the IDSDM/USB card port and not in the J_R3_PCIE_PWR connector
port.
Figure 260. Internal USB card port information
Serial COM port kit
The serial COM port kit contains the components that are listed in the table.
Table 156. Serial COM port kit
Components Quantity
Serial COM port card 1
Cable 1
For installation procedure of the serial COM port, see serial COM port section.
Upgrade Kits
313
