API Operation Frame descriptions
XBee/XBee-PRO® S2C ZigBee® RF Module
194
Extended Modem Status frame - 0x98
Description
If you enable the Verbose Join option (DC10), the device serially transmits trace messages to describe
what is happening inside the device during association.
WARNING! This option is provided for diagnostic purposes. With 4x5A/7x5A or later,
Verbose Join messages are disabled while the device is operating in Command mode.
Prior to that revision, Verbose Join messages are interspersed with serial
communications.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame data fields Offset Description
Frame type 3 0x98
Status code
4 See the following table for status code descriptions.
Status data
5
The length of this field varies with the Status Code.
Example
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x03
Checksum 6 0x5C
