API Operation Send ZDO commands with the API

XBee/XBee-PRO® S2C ZigBee® RF Module

208

Frame data fields Offset Description

Transmission options 22

All bits must be set to 0.

Data payload 23

The required payload for a ZDO command. All multi-byte ZDO

parameter values (u16, u32, 64- bit address) must be sent in little

endian byte order.

The Active Endpoints Request includes the following payload:

[16-bit NwkAddrOfInterest]

Note The 16-bit address in the API example (0x1234) is sent in little

endian byte order (0x3412).

Example

The following example shows how you can use the Explicit API frame to send an “Active Endpoints”

request to discover the active endpoints on a device with a 16-bit address of 0x1234.

Frame data fields Offset Example

Start delimiter 0 0x7E

Length MSB 1 0x00

LSB 2 0x17

Frame type 3 0x11

Frame ID 4 0x01

64-bit destination address MSB 5 0x00

6 0x00

0x00

0xFF

LSB12

0xFF

16-bit Destination

Network Address

MSB 13

0xFF

LSB 14

0xFE

Source endpoint 15 0x00

Destination endpoint 16 0x00

Cluster ID 17 0x00

18 0x05
