AT commands I/O settings commands
XBee/XBee-PRO® S2C ZigBee® RF Module
239
Bit I/O line
1 DIO1
2 DIO2
3 DIO3
4 DIO4
5 DIO5
6 DIO6
7 DIO7
8 DIO8
9 DIO9
10 DIO10
11 DIO11
Parameter range
0 - 0xFFFF (bit field)
Default
0
P0 (RSSI/PWM0 Configuration)
Select or read the function for PWM0.
Parameter range
0, 1, 3 - 5
Parameter Description
0 Unmonitored digital input
1 RSSI PWM0
3 Digital input, monitored
4 Digital output, default low
5 Digital output, default high
Default
1
P1 (DIO11/PWM1 Configuration)
Set the configure options for the device's DIO11 line.
