Digi XBee User Manual

Transmission, addressing, and routing Throughput
XBee/XBee-PRO® S2C ZigBee® RF Module
94
Hops Maximum encrypted payload Maximum unencrypted payload
16 115 160
17 105 150
18 95 140
19 85 130
20 75 120
21 65 110
22 55 100
23 45 90
24 35 80
25 25 70
Throughput
Throughput in a ZigBee network can differ by a number of variables, including:
n number of hops
n encryption enabled/disabled
n sleeping end devices
n failures/route discoveries.
Our empirical testing showed the following throughput performance in a robust operating
environment (low interference).
Configuration Data throughput
1 hop, RR, SD
58 kb/s
1 hop, RR, SE
34 kb/s
1 hop, RE, SD
Not yet available
1 hop, RR, SE
Not yet available
1 hop, ER, SD
Not yet available
1 hop, ER, SE
Not yet available
4 hops, RR, SD
Not yet available
4 hops, RR, SE
Not yet available
RR = router to router
RE = router to end device (non-sleeping)
ER = end device (non-sleeping) to router
SD = security disabled
SE = security enabled
4 hops = 5 nodes total, 3 intermediate router nodes
