MES1000, MES2000 Ethernet Switches 101

ring ring_id

0..15

Create a ring with ring_id identifier and enter the ring

configuration mode.

no ring ring_id

Remove a ring with ring_id identifier.

set ring ring_id

{enable | disable}

0..15

Enable or disable ring operation with ring_id identifier.

Ring configuration mode commands

Command line request in configuration mode appears as follows:

console(config-eaps-domain-ring)#

Table 5.94 —EAPS ring configuration mode commands

Command

Value/Default value

Action

primary-port

{gigabitethernet gi_port |

fastethernet fa_port | port-

channel group }

gi_port: (1..3/0/1..28);

fa_port: (1..3/0/1..24);

group: (1..8)

Select the primary switch port, included in the ring.

secondary-port

{gigabitethernet gi_port |

fastethernet fa_port | port-

channel group }

gi_port: (1..3/0/1..28);

fa_port: (1..3/0/1..24);

group: (1..8)

Select the secondary switch port, included in the ring.

role {master | transit}

level level-id

level-id: 0..1

Select the switch role in the configured domain and ring.

Possible roles:

- master—device is the master node

- transit—device is the transit node

- edge—adjacent node, that belongs to both primary and

secondary rings

- sub-edge—auxiliary adjacent node, that belongs to both

primary and secondary rings

role {edge | sub-edge}

EXEC mode commands

Command line request in EXEC mode appears as follows:

console#

Table 5.95 —EXEC mode commands

Command

Value

Action

show eaps [domain

domain_id [ring ring_id ] ]

domain_id: 0..63;

ring_id: 0..15.

Request the information on the state of domains and EAPS

rings.

5.16.8 G.8032v2 (ERPS) protocol configuration

ERPS ( Ethernet Ring Protection Switching) protocol allows to increase stability and robustness of

data network with ring topology by decreasing the restoration time after the failure. Restoration time

does not exceed 1 second, that is substantially lower than the network reconstruction in case of spanning

tree family protocols.

Global configuration mode commands

Command line request in global configuration mode appears as follows:

console(config)#

Table 5.96 —Global configuration mode commands

Command

Value/Default value

Action

erps

Enable ERPS protocol operation.

no erps

Disable ERPS protocol operation.

erps vlan vlan_id

1..4094

Create ERPS ring with VLAN R-APS identifier, that will be used
