ELTEX MES1000 User Manual

62 MES1000, MES2000 Ethernet Switches
5.10.1 Ethernet and Port-Channel interface parameters
Interface configuration mode commands (interface range)
console# configure
console(config)# interface { gigabitethernet gi_port | fastethernet
fa_port|port-channel group|range {…}}
console(config-if)#
This mode is available from the configuration mode and designed for configuration of interface
parameters (switch port or port group operating in the load distribution mode) or the interface range.
Selection of the interface is performed by the following commands:
for MES1024
interface fastethernet fa_port—for Fast Ethernet 1-24 interface configuration
interface gigabitethernet gi_port—for Gigabit Ethernet 1-2 interface configuration
interface port-channel group—for channel group configuration
where
– group—sequential number of the channel group, possible values (1..8)
– fa_port—Fast Ethernet interface sequential number, specified as: 1..3 /0/1..24
– gi_port—Gigabit Ethernet interface sequential number, specified as: 1..3/0/1..2
fog MES1124, MES1124M
interface fastethernet fa_port – for Fast Ethernet 1-24 interface configuration
interface gigabitethernet gi_port – for Gigabit Ethernet 1-4 interface configuration
interface port-channel group – for channel group configuration
where
– group—sequential number of the channel group, possible values (1..8)
– fa_port—Fast Ethernet interface sequential number, specified as: 1..3 /0/1..24
– gi_port—Gigabit Ethernet interface sequential number, specified as: 1..3/0/25..26
for MES2124, MES2124P, MES2124M
interface gigabitethernet gi_port—for Gigabit Ethernet 1-28 interface configuration
interface port-channel group—for channel group configuration
where
– group—sequential number of the channel group, possible values (1..8)
– gi_port—Gigabit Ethernet interface sequential number, specified as: 1..3/0/1..28
for MES2208P
interface gigabitethernet gi_port—for Gigabit Ethernet 1-12 interface configuration
interface port-channel group—for channel group configuration,
where
– group—sequential number of the channel group, possible values (1..8)
– gi_port—Gigabit Ethernet interface sequential number, specified as: 1..4/0/1..12

ELTEX MES1000 Specifications

General

Model	MES1000
Layer	L2
VLAN	Not supported
Type	Unmanaged
Power Supply	External 5V DC
Operating Temperature	0°C to +40°C
Storage Temperature	-40°C to +70°C
Humidity	10 to 90% (non-condensing)

Summary

2 PRODUCT DESCRIPTION

2.2 Device Functions

Lists and describes the basic, MAC address processing, and second-layer OSI functions of the switches.

3 INSTALLATION AND CONNECTION

4 DEVICE STARTUP, INITIAL CONFIGURATION

4.3 Configuration procedure

Outlines the necessary information and steps for initial device configuration.

5 DEVICE MANAGEMENT COMMAND LINE INTERFACE

5.2 Basic commands

Lists and describes fundamental commands available in EXEC and Privileged EXEC modes.

5.10 Interface configuration

Covers configuration of Ethernet interfaces, port channels, and VLAN interfaces.

5.14 IPv4 addressing configuration

5.15 IPv6 addressing configuration

5.27 Security functions

Explains security functions, including port security, port-based authentication (802.1x), DHCP snooping, ARP inspection, and MAC address notification.

5.31 ACL Configuration (Access Control Lists)

Explains Access Control Lists for filtering traffic based on IP, MAC addresses, and TCP/UDP ports.

5.33 Quality of Services (QoS)

6 SERVICE MENU, CHANGE OF SOFTWARE

6.2 Update of software from TFTP server
