MES1000, MES2000 Ethernet Switches 205

As soon as at least one record has been added to ACL, the last record is set by default to

deny-any-any that means that all packets, which do not fulfil ACL requirements, will be

ignored.

Table 5.247—Configuration commands for MAC-based ACLs

Command

Action

permit

{any|{source source- wildcard}

{any|destination destination_wildcard}

[vlan vlan_id]

[cos cos cos_wildcard] [eth-type]

[time-range range_name] [index index]

[offset-list offset_list_name]

Adds a permit filtration record. Packets which fulfil the record's requirements

will be processed by the switch.

deny

{any|{source source- wildcard}

{any|{ destination destination_wildcard}}

[vlan vlan_id]

[cos cos cos_wildcard] [eth-type]

[time-range range_name]

[disable-port|log-input] [index index]

[offset-list offset_list_name]

Adds a deny filtration record. Packets which fulfil the record's requirements

will be blocked by the switch. If the disable-port keyword is specified, the

physical interface receiving the packet will be disabled.

If the log-input keyword is specified, the physical a message will be sent to the

system log.

offset-list name { offset_base offset mask

value} …

Creates a user templates list with the name specified in the name field. The

name should contain from 1 to 32 characters.

One command may contain up to 4 templates having the following

parameters:

offset_base—basic offset. Possible values:

L2—beginning of Ethertype offset

outer-tag—beginning of STAG offset

inner-tag—beginning of CTAG offset

src-mac—beginning of source MAC offset

dst-mac—beginning of destination MAC offset

offset—byte offset within a packet. Basic offset is considered as a starting

point.

mask—mask. Packet analysis is performed only for the bytes digits which

have "1" specified as defined in the mask.

value—the set value.

no offset-list name

Removes a previously created list.

5.31.4 Access List Time Range Configuration (time-range)

This section describes time range configuration commands for ACL.

To create and enter the 'time-range' configuration profile editing mode, use the following

command: time-range range_name. For example, to create the time range profile named http-allowed,

you have to execute the following commands:

console#

console# configure

console(config)# time-range http-allowed

console(config-time-range)#

Table 5.248 —Time interval configuration mode commands

Parameter

Value

Action

absolute start hh:mm day month year

hh:mm: (0..23):(0..5)

day: 1..31

month: Jan .. Dec

Set the absolute time and date, when the access list takes

effect.

no absolute start

Remove the time limit
