218 MES1000, MES2000 Ethernet Switches

Exclamation mark means that copying is in progress. Each exclamation mark corresponds to

successful transfer of 10 packages with 512 bytes of information each. Point means that

during copying time-out of packages from TFTP server occurred. Several points in line can

mean that error occurred during copying.

2. With command boot select active file of system software for further loading:

console# boot system image-2

3. Make sure that active file of system software is selected correctly. To view information about

versions of software and their activeness, enter command show bootvar:

console# show bootvar

Unit Image Filename Version Date Status

---- ----- --------- --------- --------------------- -----------

1 1 image-1 3.0.0.0 17-Nov-2008 11:51:22 Active

1 2 image-2 3.0.0.0 28-Nov-2008 16:35:43 Not active*

Symbol "*" is used to mark file of software which will be executed during next loading.

4. Reboot the switch by command reload.

console# reload

This command will reset the whole system and disconnect your current

session. Do you want to continue (y/n) [n]?

Confirm reboot by entering "y”

6.2.2 Update of loading file of the device (initial loader)

Initial loader is launched just after device power switch on. With help of loading file procedure of

"system testing during switch on" (POST), unpacking and launch of system software file are performed.

When updating, the new file of initial loader is saved in flash memory instead of old one.

To view current version of loading file operating on the device, enter command show version:

console# show version

Unit SW version Boot version HW version

---------- ------------- ------------------- -----------------

1 3.0.0.0 3.0.0.0 01.00.00

Software update procedure:

1. With help of command copy copy new loading file to the device. Command format: copy

tftp://tftp_ip_address/[directory/]filename boot.

console# copy tftp://192.168.16.34/332448-10018.rfb boot

Erasing file..done.

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

Copy: 2739187 bytes copied in 00:01:18 [hh:mm:ss]
