MES1000, MES2000 Ethernet Switches 69
5.10.2 VLAN interface configuration
VLAN configuration mode commands
Command line request in VLAN configuration mode appears as follows:
console# configure
console(config)# vlan database
console(config-vlan)#
This mode is available from the global configuration mode and designed for configuration of VLAN
parameters.
Table 5.36 —VLAN configuration mode commands
Add a single or multiple VLANs.
Remove a single or multiple VLANs.
map protocol protocol
[encaps] protocols-group
group
protocol: ip, ipx, ipv6, arp,
(0600-ffff (hex)}*
encaps: ethernet, rfc1042,
llcOther
group: (1.. 2147483647)
Tether the protocol to the associated protocol group.
no map protocol protocol
[encaps]
Remove tethering.
*—protocol number (16bit).
map mac mac_address
{ host | mask } macs-group
group
mask: (9..48)
group: (1..2147483647)
Tether a single MAC address or MAC address range to MAC
address group using mask.
no map mac mac_address
{ host | mask }
map subnet ip_address
mask subnets-group group
mask: (1..32)
group: (1..2147483647)
Tether a single IP address or IP address range to IP address
group using mask.
no map subnet ip_address
mask
VLAN interface configuration mode commands (interface range)
Command line request in VLAN interface configuration mode appears as follows:
console# configure
console(config)# interface {vlan { vlan_id }|range vlan {vlan_list}}
console(config-if)#
This mode is available from the global configuration mode and designed for configuration of VLAN
interface or VLAN interface range parameters.
Selection of the interface is performed by interface vlan { vlan_id }command.
Selection of the interface range is performed by interface range vlan {vlan_list}
command.
Given below are commands for entering the configuration mode of the VLAN 1 interface and
entering the configuration mode of VLAN 1, 3, 7 group.
console# configure
console(config)# interface vlan 1
console(config-if)#
console# configure
