46 MES1000, MES2000 Ethernet Switches

port-channel group}] |

name macro-name]

macro-name:

(1..32) characters

Interface configuration mode commands

Command line request in interface configuration mode appears as follows:

console(config-if)#

Table 5.9 —Interface configuration mode commands

Command

Action

macro apply word

(1..32) characters

Apply the selected macro.

macro trace word

(1..32) characters

Validate the selected macro.

macro description word

(1..160) characters

Specify macro descriptor string.

no macro description

Delete the descriptor string.

5.5 System management commands

EXEC mode commands

Command line request in EXEC mode appears as follows:

console>

Table 5.10 —System management commands in EXEC mode

Command

Value/Default value

Action

ping [ip] {A.B.C.D|host} [size

size]

[count count] [timeout

timeout]

host (1..158) symbols;

size (64..1518)/64 Byte;

count (0..65535)/4;

timeout (50..65535) /2000

This command is used for transmission of ICMP requests (ICMP

Echo-Request) to the specified network node, and for reply

management (ICMP Echo-Reply).

- A.B.C.D—IPv4 address of the network node

- host—domain name of the network node

- size—size of the packet to be sent, the quantity of bytes in a

packet

- count—quantity of packets to be sent

- timeout—timeout of the request

ping ipv6 {A.B.C.D.E.F|host}

[size size]

[count count] [timeout

timeout]

host (1..158) symbols;

size (68..1518)/68 Byte;

count (0..65535)/4;

timeout (50..65535) /2000

This command is used for transmission of ICMP requests (ICMP

Echo-Request) to the specified network node, and for reply

management (ICMP Echo-Reply).

- A.B.C.D.E.F—IPv6 address of the network node

- host—domain name of the network node

- size—size of the packet to be sent, the quantity of bytes in a

packet

- count—quantity of packets to be sent

- timeout—timeout of the request

traceroute ip {A.B.C.D |host}

[size size]

[ttl ttl]

[count count] [timeout

timeout] [source ip_address]

[tos tos]

host (1..158) symbols;

size (64..1518)/64 Byte;

ttl (1..255)/30;

count (1..10)/3;

timeout (1..60) /3 с;

tos(0..255)/0

Detection of the traffic route to the destination node. -

A.B.C.D—IPv4 address of the network node

- host—domain name of the network node

- size—size of the packet to be sent, the quantity of bytes in a

packet

- ttl—maximum quantity of route portions

- count—maximum quantity of packet transmission attempts

for each portion

- timeout—timeout of the request

- ip_address —switch interface IP address, used for packet

transmission

- tos—type of service sent in the IP protocol header.

For description of errors, occurring during the

execution of commands, see tables 5.12, 5.13
