B.4 Operator Menu
The parameters in this group are values and statuses you typically want to view when monitoring the
operation of the S600.
Note: AVE T&P refers to the average temperature and pressure parameters. STAT&CTRL refers to
status and control parameters.
1* STATION 1
2* STATION 2
3* STREAM 1
4* STREAM 2
5* STREAM 3
6* STREAM 4
Main > Operator Menu
1. AVE T&P
2. STAT&CTRL
Station 1 (Gas EU)
1. AVE T&P
2. STAT&CTRL
3. SEQUENCE CTL
4. FBAL CTL
Station 2 (Liquid EU)
1. KF/MF LIN
2. STREAM SETUP
3. STREAM STATUS
4. METER SETUP
5. METERING IO
6. CALCULATED DATA
7. FWD AVG DATA
8. Next
1. Previous
2. CALCULATED DATA
3. FWD AVG DATA
4. REV AVG DATA
5. COMPOSITION
6. FLOW SWITCHING
Stream 1 (Gas Turbine) Stream 2 (Gas DP)
Stream 4 (Prover Ball)
1. STREAM SETUP
2. STREAM STATUS
3. METER SETUP
4. METERING IO
5. CALCULATED DATA
6. FWD AVG DATA
7. REV AVG DATA
8. Next
1. Previous
2. FWD AVG DATA
3. REV AVG DATA
4. PIPE CORRECTION
5. FLOW SWITCHING
1. PROVER ID
2. RUN CTL
3. RUN STATUS
4. CONSTANTS
5. STREAM DATA
6. HALF RUN
7. FULL RUN
8. Next
1. Previous
2. HALF RUN
3. FULL RUN
4. FINAL RUN
1. KF/MF LIN
2. PROVED DATA
3. SETUP
4. STATUS
5. METER SETUP
7. CALCULATIONS
8. Next
1. Previous
3. CALCULATIONS
4. BASE TO MTR
5. SEL TO BASE
6. COR IO
7. FLOW SWITCHING
Stream 3 (Liquid Coriolis)
Revised Aug-06 Front Panel Navigation B-3
