S600 Instruction Manual
SKT-D
SKT-F
RAWIN 1-3
DENSITY 1-2
SKT-E
DIGIN 1-6 AND 17-32
DIGOUT 1-2
Pulse Outputs 1-4
DIGIN 7-16
DIGOUT 3-12
DUAL PULSE 1-4
SPHERE SWITCH 1-4
PLLIN
RAWOUT
PLLOUT
Figure 4-20. Backplate with P154 Prover Board
Figure 4-21. P154 Prover Board
Revised Jan-07 I/O 4-17
