S600 Instruction Manual
start builds a new metering database, using the configuration data
stored in the S600’s Flash memory.
Note: You must perform a cold start if you update or otherwise change
the firmware.
7.3.1 Initiating a Cold Start
You initiate a cold start using either of two methods:
Unpowered.
Powered with operating S600.
Unpowered Cold
Start
If the S600 is not powered up, you may set bit link LK13 on the P152
CPU board to the closed (cold start) position and then apply power to
the S600. This causes the Startup menu to display.
Caution
Exercise caution if you set the bit link (jumper). When you set the cold
start jumper, remember that the S600 also uses this setting if it self-
starts for any reason, such as a low-voltage shutdown or recovery
from a malfunction. Remove the cold start jumper setting when you do
not need it. Otherwise, an unplanned restart could result in lost data.
1. Select the COLD START option from the Startup menu (see
Figure 7-1).
2. Press 1 (to keep) or 2 (to reset) the totals.
3. Press 1 to confirm the selection. The S600 displays the message
CONFIGURING – PLEASE WAIT.
The S600 builds a new database using the configuration files held
in Flash memory. When completed, the S600 Main menu displays.
Powered Cold
Start
If the S600 is currently running, you must first set the run mode to
Cold Start.
Note: The key sequence you use to access the System Status page may
vary, based on the displays for your application.
1. From the S600 Main menu, select the SYSTEM SETTINGS
option.
2. Select the SYSTEM STATUS sub-menu.
3. Press CHNG.
4. Key in your security code when the Enter Code prompt
displays.
5. Press 1 to select the Cold Start option, and press 1 again to
confirm the selection. The S600 displays a SYSTEM RESTARTING
– PLEASE WAIT
message.
The S600 now performs a reset, which concludes when the Startup
menu appears.
7-2 Startup Revised Jan-07
