S600 Instruction Manual
Chapter 2 – Installation
This chapter provides instructions on installing the FloBoss S600,
including installation preparation, procedures for mounting the panels,
and the installation and removal of plug-in boards.
In This Chapter
2.1 Preparing for Installation.....................................................................2-1
2.2 Environmental Considerations............................................................ 2-2
2.3 Required Tools for Installation............................................................2-2
2.4 Installing the S600 ..............................................................................2-3
2.4.1 Unpacking the S600 .............................................................. 2-3
2.4.2 Removing the Front Panel.....................................................2-3
2.4.3 Installing the Panel-Mounted Unit..........................................2-5
2.4.4 Reinstalling the Front Panel ..................................................2-7
2.5 Installing and Removing the Boards...................................................2-7
2.1 Preparing for Installation
The S600 installation must conform to all applicable local codes and
regulations. All installation procedures should be in accordance with
normal practices of good workmanship. Although the S600 shipped to
you may not include all of the hardware options described in this
manual, the procedure for the basic installation of the unit remains the
same.
Note: We strongly recommend you familiarize yourself with the
procedures described in this chapter before you begin to install the
S600.
The S600 uses a modular design that provides maximum flexibility and
ease of installation. The basic panel-mounted version consists of three
major components:
Fabricated metal case, complete with pre-installed PSU/backplane
and four card slots for the plug-in cards (comprising a dedicated
CPU slot and three I/O slots).
Removable front panel comprising the LCD display and keypad
assembly.
Plug-in boards. A CPU board and one I/O board are supplied for a
basic configuration; two blanking plates are supplied to cover the
unused slots.
Figure 2-1 shows the S600 system components with the appropriate
user-provided tools.
Revised Jan-07 Installation 2-1
