S600 Instruction Manual
Table 4-13. P144 I/O Bit Links (Jumpers)
Link Position Descriptions
Flash
LK1 ON Flash Write Enable
OFF
Flash Write Protected
Node Address (see Table 4-14)
LK2 ON Point to Point mode enabled
OFF
Point to Point mode disabled
LK3 – LK10 Multiplex (MUX) Addresses – see Table 4-14
LK11 ON/OFF Communications Mode – Off is only supported option
LK12 ON/OFF Oscilloscope Earth
LK13, LK14, LK15 Not Used
A/D Converter Shunts
LK16
1
ON ADC CH1 – Current Mode
OFF ADC CH1 – Voltage Mode
LK17
1
ON ADC CH2 – Current Mode
OFF ADC CH2 – Voltage Mode
LK18
1
ON ADC CH3 – Current Mode
OFF ADC CH3 – Voltage Mode
LK19
1
ON ADC CH4 – Current Mode
OFF ADC CH4 – Voltage Mode
LK20
1
ON ADC CH5 – Current Mode
OFF ADC CH5 – Voltage Mode
LK21
1
ON ADC CH6 – Current Mode
OFF ADC CH6 – Voltage Mode
LK22
1
ON ADC CH7 – Current Mode
OFF ADC CH7 – Voltage Mode
LK23
1
ON ADC CH8 – Current Mode
OFF ADC CH8 – Voltage Mode
LK24
1
ON ADC CH9 – Current Mode
OFF ADC CH9 – Voltage Mode
LK25
1
ON ADC CH10 – Current Mode
OFF ADC CH10 – Voltage Mode
LK26, LK27, LK28 Cannot be changed.
LK29, LK30 1-2/2-3 Open Collector Mode (2-3). 2-3 is only supported option.
Frequency Output Modes
LK31 ON FRQ 01 – DC Coupled
OFF FRQ 01 – AC Coupled
LK32 ON FRQ 02 – DC Coupled
OFF FRQ 02 – AC Coupled
LK33 ON FRQ 03 – DC Coupled
OFF FRQ 03 – AC Coupled
1
A/D Converter Shunts are configured in groups of five and must be used together as current or voltage. Fit
LK16 through LK19 as a set. Fit LK21 through LK25 as a set.
Revised Jan-07 I/O 4-15
