S600 Instruction Manual
Appendix B – Front Panel Navigation
This appendix describes the default menu options of the S600 front panel display. Refer to Chapter 5,
Front Panel, for a discussion of the layout and navigation basics of the S600 front panel.
The S600 software system is organized as a structured database of parameters, such as Totals, I/O,
and Calculations. The database groups the parameters logically by data points in a matrix of display
screens. For example, the parameters used for averaging totals are grouped together.
Note: The content of the display screens is specific to your application. The menus in this appendix
are provided only as an example. Although details may vary between different applications, the basic
principles described in this appendix remain the same.
For this appendix, the defaults for the screens assumed a configuration with two stations (Gas EU
and Liquid EU) and four streams (Gas Turbine, Gas DP, Liquid Coriolis, and Prover Ball). The Gas
DP stream is assigned to station 1, and the Liquid Coriolis is assigned to station 2.
Remember, your specific application may vary from these illustrations. For example, if your
application has fewer stations and more streams, you will see more stream choices and fewer station
choices than shown in this example. If you have different types of streams, you will see parameters
and submenu choices not listed here. This appendix is provided as an illustration of how to generally
navigate through the S600 front panel displays.
B.1 Main Menu
Once startup completes, the Main menu displays:
1* FLOW RATES
2* TOTALS
3* OPERATOR
4* PLANT I/O
5* SYSTEM SETTINGS
6* TECH/ENGINEER
8* CALCULATIONS
Main Menu
Revised Aug-06 Front Panel Navigation B-1
