Maintenance 13. Maintenance Parts List

S5 Rev.5 195

13. Maintenance Parts List

Be sure to specify the proper codes when ordering maintenance parts.

13.1 Standard

Part Name Code Note Ref. Maintenance

AC Servo

Motor

For Joints #1, #2

R13B000626

400 W with brake

4.1, 5.1

For Joint #3 R13B000627 200 W

with brake

6.1

For Joint #4

R13B000628

50 W with brake

7.1

For Joints #5, #6

R13B000629

50 W

8.1

Reduction

Gear Unit

For Joint #1

R13B010030

S5-A701**

4.2.2

R13B010031

S5-A901**

For Joint #2

R13B010032

S5-A701**

5.2.2

R13B010033

S5-A901**

For Joint #3

R13B010034

S5-A701**

6.2.2

R13B010035

S5-A901**

For Joint #4

R13B010036

7.2.2

For Joint #5

R13B010037

For Joint #6

R13B010038

Electromagnetic

Brake

For Joints #5

R13B030508

8.3

For Joints #6

R13B030510

8.3

Timing Belt

For Joint #2

R13B030228

5.3

For Joint #3

R13B030229

S5-A701**

6.3

R13B030230

S5-A901**

For Joint #4

R13B030231

7.3

For Joints #5, #6

R13B030232

8.2

Grease

Reduction

gear

For ALL Joints R13ZA00330100 SK-1A (500 g) -

Base

For Joint #1

R13B030303

Multemp SRL

Liquid Gasket

For ALL Joints

R13B031201

1206C

LED Lamp

R13B030006

M/C Cable

R12B020440

3 m

9.3 R12B020441 5 m

R12B020442

10 m

Cable Unit

R13B020056

S5-A701**

9.1

R13B020057

S5-A901**

Battery Unit R13B060005

Lithium battery

ER6V LY

(TOSHIBA)
