Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
PRODUCT DESCRIPTION Hardware Specifications 16
Confidential
1.4 Hardware Specifications
This section provides the printer dimensions and shows the main components.
1.4.1 Dimensions and Weight
DIMENSIONS
Figure 1-3. Dimensions
WEIGHT
1.4.2 Installation Room Requirement
Figure 1-4. Installation Room Requirement
Description Width Depth Height
Standard 2,620 mm 963 mm 1,311 mm
Maximum (Tensioner, Lift Lever and
Media Loading Lever are extended)
2,620 mm 1,259 mm 1,650 mm
Depth
Height
Width
Item Weight
Main body 146 kg
Standard Roll Unit 19.5 kg
Standard Reel Unit 21.5 kg
Legs 32 kg
Optional Roll Unit 18.5 kg
Optional Reel Unit 21.5 kg
Additional Dryer 9 kg
