DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 82
Confidential
3.4 Disassembly and Assembly Procedure
This section describes procedures for disassembling the components allowed to be
disassembled. Unless otherwise specified, disassembled units or components can be
reassembled by reversing the disassembly procedure.
3.4.1 Preparation for Servicing
3.4.1.1 Unlocking the CR Unit
 Automatic
1. Turn the printer on in Serviceman Mode.
Hold down the [Menu], [Back] and [OK] buttons and then press the power
button.
2. Select SELF TESTING - Mecha Adjustment - CR Un Cap.
3. Check that [Enter] Un Cap is displayed, and press the [OK] button.
The CR Unit is unlocked.
C A U T I O N
When you have unlocked the CR Unit and finished your
reassembly work, move the CR Unit (Print Head) over the platen
and turn the printer on to let it perform the initialization sequence.
(By this sequence, the CR Unit is locked and Print Head is capped.)
If the initialization is performed on or over the Cap, the Print Head
may be damaged.
