ADJUSTMENT Overview 217
Confidential
4.1.4 Tools/Consumables for Adjustments
The tables below show the tools required for adjusting this printer.
 Hardware Tools
 Software Tools
 Consumables
Table 4-3. Hardware tools
Tool Name Part Number Target Adjustment
Sonic tensimeter U-507
1294120
 CR Belt Tension Adjustment
 PF Belt Tension Adjustment
Standard Sheet (JETRAS
JP-D300S)
1476228
Operation check of the PE sensor.
Thickness Gauge
Commercially
available
PG Adjustment
Calibrated Loupe
Commercially
available
 Head inclination manual adjustment (CR
direction)
 Head slant manual adjustment (PF
direction)
Table 4-4. Software tools
Software Name Explanation
Service Program Used for almost all of the required adjustments.
Communication Driver To connect with the printer.
Latest version of firmware
---
Table 4-5. Consumables
Consumable Name Explanation
Media for adjustment (3M
IJ40-10R)
Used for adjustments that require paper. (For more details, see
4.1.2 Adjustment Items and the Order by Repaired Part)
Ink Cartridge
---
Cleaning Cartridge Tubes Cleaning
Waste Ink Bottle
---
