SC-S30600 Series Revision B

ADJUSTMENT NV-RAM BACKUP / NVRAM Viewer 219

Confidential

4.2 NV-RAM BACKUP / NVRAM Viewer

Parameters stored in the NVRAM on the Main Board are read/stored and written onto

the other NVRAM on the Main Board using this menu.

Also, the exported parameter information is displayed on the computer screen.

4.2.1 NVRAM Read Procedure

1. Turn the printer ON in the Serviceman Mode.

Turn the power ON while pressing [Menu] + [Back] + [OK].

2. Select the printer you want to adjust from the Model selection box.

3. Click [Get Information] on the NVRAM Read field to start reading the

parameters.

 To view the NVRAM information:

Click [Display Information] to display another screen of the NVRAM Viewer.

 To store the NVRAM information:

Click [Save]. The file is named as “serial number + acquisition date”

automatically.

4.2.2 NVRAM Write Procedure

1. Turn the printer ON in the Serviceman Mode.

Turn the power ON while pressing [Menu] + [Back] + [OK].

2. Remove all the ink cartridges.

3. Start the Service Program and select NV-RAM BACKUP from the main menu.

4. Select the printer you want to adjust from the Model Selection box.

5. Click [Open File] on the NVRAM Write field.

6. Select the NVRAM file to write on the printer.

7. Click [Write File] to start writing the parameters.

8. When the writing is completed, exit the NV-RAM BACKUP tool.

9. Turn the printer OFF.

Figure 4-2. [NV-RAM BACKUP] Screen
