SC-S30600 Series Revision B
APPENDIX Connection Diagram 297
Confidential
6.2.5 CR Unit
SUB Board
2
1
3
4
Cable No. Connection
1
PW Sensor SUB Board (CN103)
2
PG Sensor SUB Board (CN104)
3
CR Encoder SUB Board (CN102)
4
IM Sensor SUB Board (CN101
