SC-S30600 Series Revision B
APPENDIX Connection Diagram 296
Confidential
6.2.4 CR Unit
2
SUB Board
1
To Main Board/SUB-D Board
Cable No. Connection
1
Print Head SUB-D Board (CN400/CN401)
2
SUB Board (CN100) Main Board (CN100)
