Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
PRODUCT DESCRIPTION Hardware Specifications 17
Confidential
1.4.3 Part Names
FRONT SIDE
Figure 1-5. Front Side
INSIDE
Figure 1-6. Inside
Maintenance
Cover (Left)
Front Cover
After Heater
Control Panel
Ink Cartridge
Lock Lever
Cartridge Check Lamp
Media Loading Lever
Alert Lamp
Maintenance Cover (Right)
LAN Port
Tensioner
Paper Core Holder
Locking Screw
Roll Support
Auto Switch
Manual Switch
Caster
Airflow Vents
Waste Ink Bottle
Waste Ink Bottle Holder
Adjust
Waste Ink Tube
AC Inlet
USB Port
Roll Core
Holder
CR Unit
(Print Head)
Cutter
Groove
Cap
Platen Heater
Wiper
Media Holding Plate
Flushing Pad
Wiper Cleaner
Pressure Roller
