Frigidaire FFLE4033QW User Manual

106
Step: 2
Detach the connector from the Temperature Selector
Switch (See Fig. 2) and unfasten the (2) snaps to remove the
switch from the console (See Fig. 3).
11.2.4 Chime Selector
Accessibility
Step: 1
Remove the Chime knob from the console as shown in Figs.
1a and 1b.
Step: 2
Detach the connector from the Chime Switch (See Fig. 2)
and unfasten the (2) snaps to remove the switch from the
console (See Fig. 3).
11.3 Front Panel Assembly
Accessibility
Step: 1
Loosen the screws (4) of the Front panel Door Assembly as
shown in Fig.1.

Frigidaire FFLE4033QW Specifications

General

Brand	Frigidaire
Model	FFLE4033QW
Category	Laundry Appliance
Language	English
