51
3. Open the shutoff valve in the gas supply line to allow
gas to flow through the pipe. Wait for a few minutes for the
gas to move through the gas line.
4. Check for gas system leakages with a manometer. If
a manometer is not available, test all the connections by
applying a soapy water solution.
Water Connection (Steam Model
only)
6.7 Water Supply Requirements
Install hot and cold water faucets within 42 inches (107 cm)
of your washer’s water inlet. The faucets MUST be 3/4
inch (1.9 cm) with a threading for laundry hose connection.
Water pressure MUST be between 10 psi (0.69 bars) and
120 psi (8.27 bars). The pressure difference between hot
and cold water cannot be more than 10 psi. The water
department can advise you of the water pressure.
6.8 Drain System Requirements
1. Drain capable of eliminating 17 gals (64.3 L) per minute.
2. A standpipe diameter of 1-1/4 inches (3.18 cm)
minimum.
3. The height of the standpipe above the floor should
IMPORTANT
The supply line must be equipped with an approved
manual shutoff valve. This valve should be located
in the same room as the dryer and should be in a
location that allows ease of opening and closing the
valve. Do not block access to the gas shutoff valve.
WARNING
EXPLOSION HAZARD
NEVER test for gas leakages with an open flame.
To Next Page
