14.5 Motor Brake Clutch (MBC)
Accessibility
Lean down the machine safely on the floor as shown in Fig.1
so that the bottom of the machine is completely visible.
Then detach the connector (See Fig. 2) and loosen the
Screws (2) that are fitted to the Washer Tub (See Fig. 3) to
remove the Motor Brake Clutch.
14.6 Motor Gear Box Assembly
Accessibility
Step: 1
Lean down the machine safely on the floor as shown in Fig.1
so that the bottom of the machine is completely visible.
Then remove all the wire clips which are fixed to the Motor
Gear Box Assembly (See Fig.1).
Step: 2
Detach the Earth Terminal by loosening the screw which is
fitted to the leg (Dome and Bracket Assembly) (See Fig. 2).
Step: 3
Press and pull out the snap to detach the connector from
the Motor Gear Box Assembly.
