E5F: Motor Control Board fault
E5F
Wiring problem, Motor Control Board defective, Main Control Board defective.
Checks to perform:
E71
E71: Washing NTC failure
E71
Wiring open, Washing NTC defective, Wiring or Main Board defective.
Checks to perform:
WARNING
Check that all the connectors are correctly inserted.
WARNING
Check that all the connectors are correctly inserted.
Is the wiring between Main Control Board and Motor
Control Board proper? (Check for the continutity)
Replace / Repair the wiring and repeat the Diagnostic
Cycle to check for any further alarms.
Replace the Motor Control Board and check for further
alarms. Is the appliance ok?
Replace the Main Control Board and repeat the
Diagnostic Cycle to check for any further alarms.
Is the resistance measurement of the Washing NTC
approximately 50kΩ to 67kΩ? (Measure it directly on the
Washing NTC terminals without wiring) (See Fig. 1)
Replace the Washing NTC and repeat the Diagnostic
Cycle to check for any further alarms.
Reconnect the connector and measure the resistance
approximately 50kΩ to 67kΩ on the Washing NTC wiring
connector on the Main Control Board between terminals
J5-5 & J5-6. Is the Washing NTC wiring ok? (See Fig. 2)
Replace / Repair the wiring and repeat the Diagnostic
Cycle to check for any further alarms.
Replace the Main Control Board and repeat the Diagnostic
Cycle to check for any further alarms.
NO
NO
Y
E
S
NO
NO
Y
E
S
Y
E
S
