30
5.3.3 Wash Assembly
5.3.3 Wash Assembly
POS. NO DESCRIPTION
1 Washer Cabinet Assembly
2 Cushion Pads , 2 PLCS
#3 Suspension Rods Assembly, 4 PLCS
4 Pivots , 4 PLCS
5 Cushion Pads (Felt Only), 2 PLCS
6 LPA CAP
7 Screw
#8 Agitator Assembly
9 Screw,8 PLCS
10 Spin Tub Assembly
11 Hub Assembly
12 Splash Tub Assembly
13 Suspension Assembly , 4 PLCS
