152
15.10 Three Water Valves Test
Selector position Turn 4 clicks clockwise from the top
Purpose of the test To test both hot and cold and, if present, the softener water valves and the softener
siphon drains fully, agitate function
Activated components Door lock, three water valves, main motor
UI behaviour None
Working conditions Door locked, Add while water level lower than 55mm, for max. 5 minutes. The clutch
moves to the agitate position, if it was in spin. Agitate begins when the water level is
reached
15.11 Drain and Clutch Test
Selector position Turn 5 clicks clockwise from the top
Purpose of the test Drain system with the clutch mechanism
Activated components Door lock, drain pump, clutch actuator
UI behaviour None
Working conditions Door locked, drum stop, run clutch to spin mode and drain until empty +10 seconds
more. Run clutch actuator for about 100 seconds
15.12 Drain and Spin Test
Selector position Turn 6 clicks clockwise from the top
Purpose of the test Verify drain system, and Pressure Sensor calibration procedure
Activated components Door lock, main motor, drain pump
UI behaviour None
Working conditions Door locked, empty tub water level <5mm, if not the drain will run, if not in spin
mode the clutch actuator will run to spin position, spin up to maximum speed
15.13 Alarm History Test
Selector position Turn 7 clicks clockwise from the top
Purpose of the test Communicate alarm history
Activated components Buzzer
UI behaviour A series of beeps separated by a short pause for one character and a long pause to
move to the second character. Press selector for next stored alarm. Example, count
12 beeps is a C
Working conditions Drum stopped, Door unlocked
