Checks to perform:
E54
E54: Motor Centrifugal Switch 2, Heater, Thermal Limiter-2, Wiring
failure
E54
Centrifugal Switch 2 stuck open (domestic electric only), Heater open or horted
to ground, Thermal Limiter 2 open (domestic electric only), Centrifugal Switch 2
stuck closed (domestic electric only) and wiring.
WARNING
Check that all the connectors are correctly inserted
Check for the continuity between Motor Terminals (1 &
2). Is continuity there?
Replace the Motor and repeat the Diagnostic Cycle to
check for any further alarms.
Detach the connector from the Motor and measure the
resistance between terminal 5 & 4 Check Resistance
value are in between “2.6 Ω to 3.2 Ω” ? (See Fig.1)
NO
Replace the motor and repeat the Diagnostic Cycle to
check for any further alarms.
Replace the Heater and repeat the Diagnostic Cycle to
check for any further alarms.
Measure the resistance between the terminals of
Heating Element and check whether it is between 11 Ω
± 10% at room temperature (20-25°C) (See Fig.3)
NO
Replace the Heater and repeat the Diagnostic Cycle to
check for any further alarms.
Check Inlet Thermal Limiter for continuity.Is continuity
there?
Replace the Inlet Thermal Limiter and repeat the
Diagnostic Cycle to check for any further alarms.
NO
Y
E
S
Replace the Electronic Control Board and repeat the
Diagnostic Cycle to check for any further alarms.
Y
E
S
Y
E
S
Measure between all the terminals of Heating Element
and the appliance body: Is Resistance value not “0”?
(See Fig.2)
NO
Y
E
S
YES
N
O
