8. Electrical Characteristics - FFLE3911QW and FFLG4033QW
8.1 Electronic Control
The Electronic control includes the following:
1. Electronic Control Board (applicable for dryer).
2. Main Control Board (applicable for washer).
3. User Interface (UI) Board.(applicable for washer).
4. Motor Control Board (applicable for washer).
8.1.1 Electronic Control Board (Dryer)
The Electronic Control Board supplies the power supply voltage to theUser Interface (UI) Board.
The commands acquired by the User Interface (UI) Board (by turning the Program and Dryness Level selector) are sent to the
Electronic Control Board, which powers all the electrical components. (Thermistors, Thermal limiters, High limit thermostat,
Heater Assembly, Door switch and so on):
• It controls the temperature of inlet and exhaust air through the Thermistor sensor.
• It senses and controls the opening, closing and locking conditions of the door.
• It controls the motor operations (Speed of rotation, direction and so on) and safeguards against overload with the help of
Thermal Overload Protector (If equipped)
• It controls the functions of Thermal Limiter Switches, Thermistors and High limit Thermostat.
